Description
Features
- Low Insertion Loss
- Low PDL
- High Isolation
- Excellent Environment Reliability
Applications
- WDM System
- MAN
- CATV System
| Technical Parameters | |||||||||||||
| Out sheath Diameter | Tight Buffer Diameter | Weight | Minimum allowable Tensile Strength (N) | Minimum allowable Crush Load (N/100mm) | Minimum Bending Radius (MM) | Storage temperature | |||||||
| (MM) | (MM) | (KG) | short term | long term | short term | long term | short term | long term | (°C) | ||||
| 1.6 | 0.6 | 2.80 | 150 | 80 | 500 | 100 | 20D | 10D | -20+60 | ||||
| 1.8 | 0.6 | 3.00 | 150 | 80 | 500 | 100 | 20D | 10D | -20+60 | ||||
| 2.0 | 0.9 | 4.25 | 150 | 80 | 500 | 100 | 20D | 10D | -20+60 | ||||
| 2.4 | 0.9 | 5.00 | 150 | 80 | 500 | 100 | 20D | 10D | -20+60 | ||||
| 2.8 | 0.9 | 6.60 | 150 | 80 | 500 | 100 | 20D | 10D | -20+60 | ||||
| 3.0 | 0.9 | 7.00 | 150 | 80 | 500 | 100 | 20D | 10D | -20+60 | ||||
| Optical Characteristics | ||||||||||||||
| Fiber Sort | Multimode | G.651 | A1a:50/125 | Graded-index fiber | ||||||||||
| A1b:62.5/125 | ||||||||||||||
| Singlemode | G.652(A、B、C、D） | B1.1: Conventional fiber | ||||||||||||
| G.653 | B2: Zero dispersion shifted | |||||||||||||
| G.654 | B1.2: Cut-off wavelength shifted | |||||||||||||
| G.655 | B4: Main technical data for positive dispersion shifted single-mode fiber | |||||||||||||
